< Delphi FG0517 Fuel Pump Module Assembly - Actual OE Part
Delphi FG0517 Fuel Pump Module Assembly - Actual OE Part For A 2004 Chevrolet Malibu
Fits Vehicle: 2004
Chevrolet
Malibu
Engine: 3.5L/213ci V6
Sub Model: LS
Sub Model: LT
Required Per Vehicle: 1
Retail Price: $769.99
Sale Price:
$533.01
Shipping: Free!
Features
- Internal springs increased durability and enhanced stability prevents tube chafing
- Lower amperage draws less load on vehicle's electrical system
- Fuel level goldfilled sensors provide improved resistance to sulfur corrosion and heat resistance
- Empty float height and float retention is to exact OE specifications guaranteeing correct gas gauge reading
- Fill Line Size: 15.8this is a test
- Fill Line Style: Female QCthis is a test
- Fill Vapor Valve: Yesthis is a test
- Flow Rate: 17.1 g/sthis is a test
- Fuel Pressure Reg: Yesthis is a test
- Fuel Type: Gasolinethis is a test
- Harness/Jumper: Nothis is a test
- Mount Type: In-Tankthis is a test
- OE Type/Exact Fit: OEthis is a test
- Return Line Size: 7.9mmthis is a test
- Return Line Style: Male QCthis is a test
- Shut Off Pressure: 550 - 750 kPathis is a test
- Strainer Location: Internalthis is a test
- Supply Line Size: 9.5mmthis is a test
- Supply Line Style: Female QCthis is a test
- System Pressure: 380 kPathis is a test
- Type/Series: Fuel Delivery Modulethis is a test
- Vapor Press Sensor: Yesthis is a test
- Vapor Vent Line: Nothis is a test
- Warranty: 12 mos/12,000 milesthis is a test
Description
Internal springs increased durability and enhanced stability prevents tube chafing. Lower amperage draws less load on vehicle's electrical system. Fuel level goldfilled sensors provide improved resistance to sulfur corrosion and heat resistance. Empty float height and float retention is to exact OE specifications guaranteeing correct gas gauge reading
Manufacturer Information
Item Number: FG0517
Approximate Item Package Dimensions: 23.63" x 11.63" x 8.25"
Approximate Item Package Weight: 3.13 lbs
